SuperDekk Service Truck
A Service Truck for the tire company SuperDekk Sp/f (member of First Stop network owned by Bridgestone). The truck will be servicing heavy machinery on Faroe Islands.
The walls and ceiling of the box are made of sandwich panel. The sides of the box extend from the aluminum profile frame to the bottom of the cab.
Lighting: Inside the box there are two 2,5 m LED strips. Outside: LED side lights on both sides, at the top and bottom of the vehicle; 6 working lights; 6 stroboscope LED flash-lights.
The truck is fitted with:
The Dynaset hydraulic piston compressor engineered in Finland that will be used for filling the large excavator tires is quite extraordinary. The only power source needed is a hydraulic system of the base machine, PTO (Power Take Off), which provides the compressor the required hydraulic flow and pressure. The compressor converts the hydraulic power into high quality compressed air. There are also 2 x 160 L air tanks mounted on the vehicle to ensure the necessary air pressure.
Inside dimensions of the box: Length 1240 mm, width 2240 mm, height 1900 mm.
Vehicle dimensions: Length 7068 mm, width 2306 mm, height 2450 mm.
Vehicle base: Iveco Daily 35C18.
Eventtents Service Truck
Eventtents is a company that installs large event and production tents mainly in Scandinavia. The Service Truck is used for the transportation of equipment and crew.
The truck has many storage spaces. Most importantly, on both sides, at the back, there are two cupboards with twin doors (opening of 1250 x 1750 mm), that are connected to each other by a passageway underneath the truck (to store forklifts). On both sides of the front of the truck, there are cupboards with twin doors (1340 x 2000 mm opening).
The truck body is insulated to keep the crew warm in winter and cool in summer. The front of the ceiling is designed to extend to the roof of the cab, providing additional storage space.
The truck is fitted with an intelligent inverter (700 W), generator (2,5 kW) and a winch for setting up large tents. Inside, there is sufficient surface space to work on and an Aluca aluminium racking system to store smaller equipment and tools.
Inside dimensions of the box: length 3940 mm, width 2240 mm, height 2240 mm.
Vehicle base: Iveco Daily 35C18 Double – 4100
Baltem Komatsu Service Truck
The truck is used for servicing Komatsu machinery. The most important feature is the Fassi loader crane fitted to the back of the truck with lifting capacity of up to 3 tm. The remotely controlled crane is used to lift heavy parts onto the transport platform at the rear end of the truck.
The truck body is insulated to keep the mechanics warm in winter and cool in summer. There is also an extra heating system in the back. The roof window adds light and ventilation.
The truck is fitted with air compressor, welding machine and various hand tools. There is sufficient surface space to work on and a racking system to store all the equipment and spare parts.
Rotator Service Truck
Thicker insulation layer and an extra heater unit makes it possible to use this service truck in the extreme weather of Northern Finland.
The subframe is glued to the floor panel which makes the truck floor about 10 cm lower and easier for the mechanics to step to and from the vehicle.
The remotely controlled Zepro tail-lift in the back has a lifting capacity on 1 t. The truck is equipped with an Oil-Bar on the right side of the vehicle with a hatch opening upwards which has four different tankers. The used oil compartment inside the frame of the vehicle takes up to 470 l fluid.
There are 2 roof windows for extra light and ventilation in the back. Top quality LED working lights on the rear and sides of the vehicle enable the mechanics to work outside in the darkness and stroboscope LED flash-lights make the vehicle identifiable. The reverse camera in the back makes manoeuvring a breeze.
